BioDuo (Micro + 2L) Combo Dual-Head Pump (0.005–2000 mL/min)
BioDuo (Micro + 2L) Combo Dual-Head Pump (0.005–2000 mL/min)
BioDuo (Micro + 2L) Combo forms a powerful, adaptable dual-head peristaltic pumping platform covering 0.005–2000 mL/min at 0.1–200 RPM. Independently driven Micro and 2L heads let you run ultra-low-flow dosing and high-volume transfer on the same unit, with Timed, Single and Multi-Dose modes for precise, continuous operation. The unified design provides a scalable path from R&D to pilot and production without changing hardware.
BioDuo (Micro + 2L) Combo
Catalogue
Mode Type
Download
Overview
BioDuo (Micro +2L) Combo form a powerful, adaptable pumping platform designed to meet a broad spectrum of laboratory & process needs – from ultra-low flow precision to high-volume throughput. Together, the BioDuo (Micro + 2L) Combo provide a scalable, unified solution that covers a wide flow range, enabling users to seamlessly transition from R&D to scale-up without changing hardware platforms.
Features and Benefits
-
Transfer Mode: User can set at desired RPM or Flow rate.
-
Dispensing Mode: Timed Dose, Single Dose & Multi Dose.
-
Dose Volume: From 0.5 mL onwards (Micro), 1 mL onwards (2L).
-
Flow Rate: 0.005 mL /min to 2000 mL/min
-
External Control: Analog (4-20mA / 0-10V), Digital (RS232).
-
21 CFR Compliant
Specifications
RPM Range
0.1 – 200
Flow Range
0.005 – 2000 mL/min
Volume Dispensed in Dose & Multi Dose Mode
0.5 mL onwards
Number of Profiles
100 for individual Pump Heads
Compatible Tubing
Silicone (1.6mm Wall Thickness)
Timed Dosing
From 1 minute to 23 hours 59 minutes
Wait Interval Range
From 1 second to 59 minutes
Traceability
Security
3 Levels Securities Logins, 21 CFR Compliant
Connections
RS232, 4-20mA, 0-10V, Bluetooth
Gross Weight & Dimension
Dimensions ( L x W x H )
294 x 171 x 186 mm
Net weight
5 Kg
Enclosure Design
Compliant to IP31
BioDuo Micro (0.1-200 RPM)
Rotor For | Tubing ID (mm) | Tube Size # | Min Flow Rate (mL/min) | Max Flow Rate (mL/min) |
|---|---|---|---|---|
Tube Wall 1.6 mm | 0.8 | 13# | 0.005 | 20 |
Tube Wall 1.6 mm | 1.6 | 14# | 0.08 | 45 |
Tube Wall 1.6 mm | 2.4 | 19# | 0.15 | 105 |
Tube Wall 1.6 mm | 3.2 | 16# | 0.3 | 120 |
BioDuo 2L (0.1-200 RPM)
Rotor For | Tubing ID (mm) | Tube Size # | Min Flow Rate (mL/min) | Max Flow Rate (mL/min) |
|---|---|---|---|---|
Tube Wall 1.6 mm | 3.2 | 16# | 0.5 | 310 |
Tube Wall 1.6 mm | 4.8 | 25# | 0.5 | 625 |
Tube Wall 1.6 mm | 6.4 | 17# | 0.6 | 1050 |
Tube Wall 1.6 mm | 7.9 | 18# | 0.8 | 1550 |
Tube Wall 1.6 mm | 9.5 | - | 1.5 | 2000 |
